Nuheat Mat 120V Floor Radiant Heating Heat Mat

Cold feet? Not with Nuheat!

Nuheat mats provide radiant floor heating to any room. Nuheat floor heating mats are easy to install and add comforting warmth to many flooring surfaces, including tile, stone, laminate, and engineered wood.

Features

Nuheat mat thickness: 1/8"
Installation is fast and easy - Use a 1/4" layer thin-set to adhere the Nuheat mat to the subfloor
Energy efficient
It can be controlled with many thermostats (Click here for )
Provides radiant floor heat to tile, stone, granite, laminate, and engineered wood
Multiple Nuheat mats can be used together to provide underfloor heat to the whole room
Nuheat mats come in many sizes and are available in both 120 & 240-volt formats (click here for )
Covered by a 25-year warranty

Custom Nuheat Mat Sizes

Need help finding the size you need? Custom Nuheat Mats are available for special orders! Follow the and send your room layout to [email protected] for a complete quote.

120 Volt Floor Heating Cable Specifications
Model	Volts	Watts	Amps	Ohms	Sq. Ft.	Dimensions (Inch)
F1006	120	90	0.8	160	7.5	40 x 27
F1008	120	107	0.9	135	8.9	40 x 32
F1010	120	133	1.1	108	11.1	40 x 40
F1012	120	160	1.3	90	13.3	40 x 48
F1206	120	96	0.8	150	8	48 x 24
F1208	120	120	1	120	10	48 x 30
F1209	120	144	1.3	100	12	48 x 40
F1212	120	192	1.6	75	16	48 x 48
F1506	120	120	1	120	10	60 x 24
F1508	120	150	1.3	96	12.5	60 x 30
F1509	120	180	1.5	80	15	60 x 36
F1510	120	210	1.8	69	17.5	60 x 42
F1512	120	240	2	60	20	60 x 48
F1515	120	300	2.5	48	25	60 x 60
F1806	120	144	1.2	100	12	72 x 24
F1008	120	180	1.5	80	15	72 x 30
F1809	120	216	1.8	67	18	72 x 36
F1810	120	252	2.1	57	21	72 x 42
F1812	120	288	2.4	50	24	72 x 48
F1815	120	360	3	40	30	72 x 60
F1818	120	432	3.6	33	36	72 x 72
F2106	120	168	1.4	86	14	84 x 24
F2108	120	210	1.8	69	17.5	84 x 30
F2109	120	252	2.1	57	21	84 x 36
F2110	120	294	2.5	49	24.5	84 x 42
F2112	120	336	2.8	43	28	84 x 48
F2115	120	420	3.5	34	35	84 x 60
F2118	120	504	4.2	29	42	84 x 72
F2121	120	588	4.9	24	49	84 x 84
F2506	120	192	1.6	75	16	96 x 24
F2508	120	240	2	60	20	96 x 30
F2509	120	288	2.4	50	24	96 x 36
F2510	120	336	2.8	43	28	96 x 42
F2512	120	384	3.2	38	32	96 x 48
F2515	120	480	4	30	40	96 x 60
F2518	120	576	4.8	25	48	96 x 72
F2521	120	672	5.6	21	56	96 x 84
F2525	120	768	6.4	19	64	96 x 96
F2706	120	216	1.8	67	18	108 x 24
F2708	120	270	2.3	53	22.5	108 x 30
F2709	120	324	2.7	44	27	108 x 36
F2710	120	378	3.2	38	31.5	108 x 42
F2712	120	432	3.6	33	36	108 x 48
F2715	120	540	4.5	27	45	108 x 60
F2718	120	648	5.4	22	54	108 x 72
F2721	120	756	6.3	19	63	108 x 84
F2725	120	864	7.2	17	72	108 x 96
F2727	120	972	8.1	15	81	108 x 108
F3006	120	236	2	61	19.7	118 x 24
F3008	120	295	2.5	49	24.6	118 x 30
F3009	120	354	3	41	29.5	118 x 36
F3010	120	413	3.4	35	34.4	118 x 42
F3012	120	472	3.9	31	39.3	118 x 48
F3015	120	590	4.9	24	49.2	118 x 60
F3018	120	708	5.9	20	59	118 x 72
F3021	120	826	6.9	17	68.8	118 x 84
F3025	120	944	7.9	15	78.7	118 x 96
F3027	120	1062	8.9	14	88.5	118 x 108
